PRODUCTS DETAILS

KPM 36 Full Autmatic multi-layer concrete paving stone manufactoring machine.

Upon conducting a comparison, taking the machine cost, production capacity and production cost into consideration, KPM 36 FULL AUTOMATIC, capable of manufactoring 8 lines of product on a single palette, will certainly be more attractive to the pavement manufacturers.

Forms an 8m2 stones pile in a very short period of time.

Regardless of the stone type, stamps stone in adequate capacity to form a 1m2 area per each stamping.

In case height of stone stamped goes down under 80mm, number of lines of piles goes up.


Max.Length 13700 mm Max.Width 6500 mm
Max.Height 4150 mm Max.Product Height 300 mm
Min.Product Height 50 mm Pallet sizes 1300 x 1150 mm
Number of Hydraulic Pumps 5 Hydraulic tank kapacity 1000 ltr.
Hydraulic flow rate 137 ltr./min Flow rate of circulation 150 ltr./min
Average hydraulic pressure 150 bar Cycle time 38 ÷45 sec.
Volume of Morta Bunker 2x1800 ltr. Number of bottom vibrators 2 pcs.
Number of top vibrators 4 pcs. Total electric power 80,72 Kw
